Hygienic fittings DIN EN 10357-A

BEND 90 BS DN80 HSF3 1.4404


DIN 11852
9611309181

BEND 90 BS DN80 HSF3 1.4404


DIN 11852
9611309181
Lead time on request
  • 100% DIN standard
  • Hygienic and aseptic
  • Controlled tolerances and geometry
  • Weldability
  • Uniform surface appearance

Documentation

Tubes and Fittings Product leaflet (en-US)PDF
Hygienic fittings DIN EN 10357-A Product leaflet (en-US)PDF
3D model for item - 9611309181 (en)UNKNOWN

Technical details

Range
Bends
Product Model
DIN EN 10357-A Bends 90 EN 10374-A
Size
DN80
Material
1.4404 (316L)
Finish
HSF3 (ID≤0.8/OD≤0.8)
Connection type
Weld ends
Standard
DIN 11852 EN 10374-A
Design
BS
OD/ID x t
85.00/81.00 x 2.00
OD1/ID1 x t1
85.00/81.00 x 2.00
Dimension L, mm
90.00
Dimension R, mm
90.00
Weight - Net (Kg)
0.56 kg
Net weight
0.559 kg
