AVH Blindplate - With Connection & CIP
9615121901
- Minimal risk of tank collapse due to internal vacuum conditions
- Fully cleanable via built-in Cleaning-in-Place nozzle
- Easy to integrate
- Low investment due to simplified installation
- Can be combined with other valves in a customized tank top
Description
BLIND PLATE AVH 3-4" - PRESSURE RELIEF VALVE Ø75
Technical details
Valve accessory type
Blind plateValve type
SB Anti Vacuum HouseSize inch
3 - 4Size mm
76.1 - 101.6Product wetted steel part
1.4307 (304L)Outside surface quality
Ra ≤ 1.6 μmInside surface quality
Ra ≤ 1.6 μmDimension h mm
73Dimension h inch
2.87Dimension w mm
200Dimension w inch
7.87Weight - Net (Kg)
5 kg
