AVH Drain Collector with Force Opener
9615073913
- Minimal risk of tank collapse due to internal vacuum conditions
- Fully cleanable via built-in Cleaning-in-Place nozzle
- Easy to integrate
- Low investment due to simplified installation
- Can be combined with other valves in a customized tank top
Description
DRAIN COLLECTOR FORCE OPN - 4" AVH
Technical details
Valve accessory type
Drain CollectorValve type
SB Anti Vacuum HouseSize inch
4Size mm
101.6Connection type
DINProduct wetted steel part
1.4307 (304L)Outside surface quality
BlastedInside surface quality
BlastedDimension h mm
121Dimension h inch
4.77Dimension w mm
165Dimension w inch
6.50Proximity switch
NoForce opener
YesWeight - Net (Kg)
3 kg
