Unique DV-ST UltraPure

DV-ST UP OCA 2-W DN15 ASME BPE


CL 0.5 SF1 TFM/EPDM MAN SS/SS QDOC
9615037147

DV-ST UP OCA 2-W DN15 ASME BPE


CL 0.5 SF1 TFM/EPDM MAN SS/SS QDOC
9615037147
Dodacia lehota na vyžiadanie

Dokumentácia

Unique DV-ST UltraPure Product leaflet (en)PDF
Unique DV-ST UltraPure - Pneumatic (DN8-DN100) Instruction manual (en)PDF
3D model for item - 9615037147 (en)UNKNOWN
Unique DV-ST UltraPure - manual, valve sizes DN8-DN100 (¼" to 4") Instruction Manual (en)PDF

Technické detaily

Product Model
DV-ST 2-way valve
Connection type
Clamp
Port size
DN15,½"
Outlet port size
None
Tube standard
ASME BPE
Material type
Cast
Diaphragm material
TFM/EPDM
Pneumatic actuator
Nie
Actuator material
SS/SS
Body type
2-way
Main port size
None
Manual handle
Áno
Minimized seat size
Áno
High pressure
Nie
Surface finish
Ra 0,5 (SF1)
Certificate
Q-doc certificate
Valve type
DV-ST
Dimension l mm
108
Drain angle x c
35.2°
Inner diameter mm
9.40
Outer diameter mm
25
Net weight
0.28 kg
