- Features a durable and dependable design with rugged plastic stem bushings, which eliminate metal-to-metal galling.
- The stem is threaded to the actuator shaft, eliminating the coupling between the stem and actuator, thereby ensuring proper alignment.
- A robust, heavy-duty bonnet and body ferrule design that will stand up to years of hammering from hydraulic shock.
- Enhanced product safety due to the static seal leak detection.
Description
761TR-23M-20S-20-U-2-NNN - VALVE
Technical details
Size inch
2.0Size mm
50.8Connection type
Tri-ClampActuator function
Normally closedActuator option
Standard StrokeBody combination
Upper tee/Lower crossBody function
Change-overProduct wetted steel part
316L Stainless SteelPort configuration
23Elastomer
BunaInside surface quality
32 Ra standardOutside surface quality
3A brightPlug Seal Type
TRWeight - Net (Kg)
12.23 kg
