Hygienic fittings DIN EN 10357-A

UNION S DN125 HSF0 1.4307 EPDM

9612151347

UNION S DN125 HSF0 1.4307 EPDM

9612151347
Lead time on request
  • 100% DIN standard
  • Hygienic and aseptic
  • Controlled tolerances and geometry
  • Weldability
  • Uniform surface appearance

Description

UNION S DN125 HSF0 1.4307 EPDM - DIN 11851

Technical details

Range
Connections
Product Model
DIN EN 10357-A Threaded Unions DIN 11851 S
Size
DN125
Material
1.4307/EPDM
Finish
HSF0 (ID=0.8/OD=1.6)
Connection type
Weld ends
Standard
DIN 11851
Design
S
OD/ID x t
129.00/125.00 x 2.00
Dimension A, mm
178.00
Dimension B
70.00

Documentation
