- Greater process safety
- Low initial cost of investment
- Compact design
- Superior hygiene
- Easy installation
Description
Counter Flange AVV D100 - WELDING FLANGE @100
Technical details
Valve accessory type
Counter flangeValve type
SB Anti Vacuum ValveSize mm
100Product wetted steel part
1.4404 (316L)Outside surface quality
Ra ≤ 1.6 μmInside surface quality
Ra ≤ 0.8 μmDimension h mm
70Dimension h inch
2.76Dimension w mm
200Dimension w inch
7.87Weight - Net (Kg)
4.7 kg
